Specifications

• Dimensions

  add remove
  • Length:
    86.0 in
  • Seat height, unladen:
    29.9 in
  • Dry Weight:
    545 lbs
  • Ground clearance:
    5.5 in
  • Rake (steering head):
    30
  • Trail:
    4.6 in
  • Wheelbase:
    59.6 in
  • Tires, front specifications:
    100/90B19 57H
  • Tires, rear specifications:
    150/80B16 77H
  • Fuel Capacity:
    3.3 gal
  • Oil capacity:
    2.8 qt.
  • Weight, as shipped:
    545 lbs
  • Weight, in running order:
    564 lb
  • Luggage capacity – volume:
    N/A
• Engine

  add remove
  • Engine:
    Air-cooled, Evolution®
  • Bore:
    3.0 in
  • Stroke:
    3.8 in
  • Displacement:
    53.88 in³
  • Compression ratio:
    09:01
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    Black exhaust headers and black mufflers
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    50.2 ft-lb
  • Engine torque (RPM):
    4750
  • Lean angle, right (deg.):
    27
  • Lean angle, left (deg.):
    28
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    0.02 mpg
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions :
    111 g/km CO2
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/57 ratio
  • Gear ratios (overall) 1st:
    10.41
  • Gear ratios (overall) 2nd:
    7.436
  • Gear ratios (overall) 3rd:
    5.531
  • Gear ratios (overall) 4th:
    4.584
  • Gear ratios (overall) 5th:
    3.931
  • Gear Ratios (overall) 6th:
    N/A
• Chassis

  add remove
  • Wheels, optional style type:
    N/A
  • Wheels, front type:
    Black 9 Spoke with Machined Highlights
  • Wheels, rear type:
    Black 9 Spoke with Machined Highlights
  • Brakes, caliper type:
    Dual-piston front, Dual-piston rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
  • Gauges:
    Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
